About Flexible PCB Boards
We offer a wide range of PCB products, including single-layer, double-layer, and multi-layer PCBs, catering to various electronic applications.
Featured Flexible PCB Boards
| Item | Parameter | Item | Parameter |
|---|---|---|---|
| Layers | FPC:1-14Layers Rigid Flex Board:2-10layers | Surface Treatment | OSP;Flash Gold;Immersion Tin;Flash Tin; |
| Main Products | LED FPC、Impedance Board、Module board、Rigid Flex Board、Others | Flash Gold | Ni:2.54-9um;Au:0.025-0.2um |
| Min/Max.Board Size | Min Board Size : 5*8mm ; Max Board Size:5000*500mm | Immersion Gold | Ni:2.54-6um;Au:0.025-0.123um |
| Laminates | PI/PET/PEN | Immersion Tin | 0.6-1.2um |
| NPTH Dia.Tolerance | ±1mil(±0.075mm) | Electric tin | 3-10um |
| Board Thickness Tolerance | ±0.03mm | Impedance Control | ±10% |
| Min.Track Width | 0.05mm | Min.Hole Size | 0.1mm |
| Mix.Track Space | 0.05mm | Min.Board Thickness | 0.05mm |
| Acessaries | PI、Steel、FR4、Alu、Shielding、Carbon、Silver oil | Special process | Raised dot board、single layer different panel、 hollow board |
